95 Ceramic Electrical Insulation Rod

  • 95 Ceramic Electrical Insulation Rod
Place of Origin Hunan,China
Brand Name Antaeus
Certification /
Model Number AD-R016
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Inner vacuum packaging, outside carton.
Delivery Time 15-45 days
Payment Terms T/T or Negotiation
Supply Ability Full Supply

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Alumina Ceramic Insulator Material Fine Aluminum Oxide
Density 3.7g/cm3-5.9g/cm3 Size L:0.5mm-300mm
Working Temperature 1650℃ Application Alumina Ceramic Insulator For Oxygen Sensor
Process Grinding ID 0.5-60mm
OD 0.5-120mm
Highlight

95 Ceramic Electrical Insulation Rod

,

300mm Electrical Insulation Rod

,

0.5mm 95 Ceramic Electrical Insulators
Leave a Message
Product Description

Alumina Ceramic Insulator /Electrical Insulation Rod For Oxygen Sensor



1. Description:

Alumina ceramic insulator(especially high alumina ceramic) for electrical industry is used for many decades as insulators or enclosures for electrical components. Additionally, it has been incorporated into many appliance, aerospace and automotive applications where moderate strength, low cost and good electrical resistance are required. This ceramic material can be formed into complex shapes prior to sintering, which has led to wide usage in a variety of applications.



2. Feature Advantages:

1) Abrasion resistance

2) Impact resistance

3) High hardness and high density

4) Low thermal conductivity

5) Chemical inertness

6) Good wear resistance



3. Material Features / Properties:

Composite (wt %) 99% 99.5% 99.8%
Color   White or Ivory White or Ivory White or Ivory
Density g/cm 3 3.82 3.9 3.92
Hardness HRA 83 85 85
Flexural Strength Mpa (psi*10 3 ) 375 386 381



4. Technical Parameters:

Technical Parameters of Ceramics
Items Test Conditions Unit or Symbol 99% AL2O3 95% AL2O3 90% AL2O3 Zirconia Steatite Silicon Carbide
Volume Density -- g/cm3 ≥3.70 ≥3.62 ≥3.40 ≥5.90 ≥2.60 ≥3.08
Tightness -- Pa·m³/s ≤1.0×10-11 ≤1.0×10-11 ≤1.0×10-11 - - -
Liquid Permeability -- -- Pass Pass Pass   Pass -
Flexural Strength - MPa ≥300 ≥280 ≥230 ≥1100 ≥120 ≥400
Elastic Modulus - GPa - ≥280 ≥250 ≥220 - 400
Poisson Ratio - 　 - - 0.20～0.25 0.20～0.25 - - -
Thermal Shock Resistance 800℃( Room Temperature) Cycle: 10 times   Pass Pass Pass - - -
Coefficient of Linear Expansion 20℃～100℃ ×10-6 K-1 - - -   ≤8 -
20℃～500℃ ×10-6 K-1 6.5～7.5 6.5～7.5 6.5～7.5 6.5～11.2 - -
20℃～800℃ ×10-6 K-1 6.5～8.0 6.5～8.0 6.3～7.3   - 4
20℃～1200℃ ×10-6 K-1 - 7.0～8.5 - - - -
Coefficient of Thermal Conductivity 20℃ W/(m·k) - - - - - 90～110
1000℃
Dielectric Constant 1MHz 20℃ - 9.0～10.5 9.0～10 9.0～10 - ≤7.5 -
1MHz 50℃ - - 9.0～10 - - - -
10GHz 20℃ - 9.0～10.5 9.0～10 9.0～10 - - -
Volume Resistivity 100℃ Ω·cm ≥1.0×1013 ≥1.0×1013 ≥1.0×1013 - ≥1.0×1012 -
300℃ ≥1.0×1013 ≥1.0×1010 ≥1.0×1013 - - -
500℃ ≥1.0×109 ≥1.0×108 -- - - -
Disruptive Strength D.C kV/mm ≥17 ≥15 ≥15 - ≥20 -
Chemical Durability 1:9HCl mg/c㎡ ≤0.7 ≤7.0 - - - -
10%NaOH mg/c㎡ ≤0.1 ≤0.2 - -- - -
Grain Size - μm - 3~12 - - - -



5. Process Flows:

Formulating --- Granulating --- Forming --- Sintering --- Grinding --- Inspecting --- Packing

95 Ceramic Electrical Insulation Rod 0



6. Application Fields:

New energy vehicles, automotive industry, motorcycles, recreational cars, industrial automation, commercial cars and so on.



95 Ceramic Electrical Insulation Rod 1



7. Production Facilities: Prilling Tower , Forming Machine , High Temperature Sintering Kiln

95 Ceramic Electrical Insulation Rod 2



8. Detection Devices:

Electric Performance Tester , Film Thickness Analyzer , Granulometer , Helium Mass Spectrometer Leak Detector , Universal Pull Force Meter

95 Ceramic Electrical Insulation Rod 3



9. Notes:Above information only for reference and please contact with us for more details freely when you have any inquiry!
