High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc

  • High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc
  • High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc
Place of Origin Hunan,China
Brand Name Antaeus
Certification /
Model Number AD-D021
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Inner vacuum packaging, outside carton.
Delivery Time 15-45 days
Payment Terms T/T or Negotiation
Supply Ability Full Supply

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Electronic Ceramic Components / Electronic Ceramics AL2O3 Content 90% - 99%
Tensile 30 Kpsi - 32 Kpsi Flexural 55 Kpsi - 60 Kpsi
Compressive 300 Kpsi - 330 Kpsi Density 3.7 G/cc - 3.92 G/cc
Hardness 13.8 HV, Gpa - 18 HV, Gpa Thermal Conductivity 25 W/(m K) - 32 W/(m K)
C.O.T.E 75 In / In°C (x10^7) - 78 In / In°C (x10^7) Working Temperature 1500 °C - 1750 °C
Dielectric Constant 9.5 - 9.8 Volume Resistivity >10^14 Ohm-cm
Dielectric Strength 16 KV/mm - 20 KV/mm
Highlight

3.92 G/Cc Electronic Ceramic Components

,

95% Electronic Ceramic Components

,

3.7 G/Cc high purity ceramics
Leave a Message
Product Description

Electronic Ceramic Components / Ceramic Electronic Parts



1. Description:

Piezoelectric actuators are forming a new field midway between electronic and structural ceramics (Uchino, 1993, 1994, 1995b, 1996). Application fields are classified into three categories: positioners, motors, and vibration suppressors. The manufacturing precision of optical instruments such as lasers and cameras, and the positioning accuracy for fabricating semiconductor chips, which are adjusted using solid-state actuators, is of the order of 0.1 µm. Regarding conventional electromagnetic motors, tiny motors smaller than 1 cm are often required in office or factory automation equipment, and are rather difficult to produce with sufficient energy efficiency. Ultrasonic motors whose efficiency is insensitive to size are superior in the minimotor area. Vibration suppression in space structures and military vehicles using piezoelectric actuators is also a promising technology.



2. Feature Advantages:

1) High hardness and high density

2) Low thermal conductivity

3) Chemical inertness

4) Good wear resistance

5) High Fracture toughness

6) Good insulation performance

7) High temperature resistance

8) A variety of specifications is available

9) Satisfy various technical requests

10) Lower medium spoilage

11) Stiffness texture

12) Chemical inertness

13) Good wear resistance

14) High Fracture toughness

15) Good insulation performance



3. Material Features / Properties:

Composite (wt %) 99% 99.5% 99.8%
Color   White or Ivory White or Ivory White or Ivory
Density g/cm 3 3.82 3.9 3.92
Hardness HRA 83 85 85
Flexural Strength Mpa (psi*10 3 ) 375 386 381



4. Technical Parameters:

Technical Parameters of Ceramics
Items Test Conditions Unit or Symbol 99% AL2O3 95% AL2O3 90% AL2O3 Zirconia Steatite Silicon Carbide
Volume Density -- g/cm3 ≥3.70 ≥3.62 ≥3.40 ≥5.90 ≥2.60 ≥3.08
Tightness -- Pa·m³/s ≤1.0×10-11 ≤1.0×10-11 ≤1.0×10-11 - - -
Liquid Permeability -- -- Pass Pass Pass   Pass -
Flexural Strength - MPa ≥300 ≥280 ≥230 ≥1100 ≥120 ≥400
Elastic Modulus - GPa - ≥280 ≥250 ≥220 - 400
Poisson Ratio - 　 - - 0.20～0.25 0.20～0.25 - - -
Thermal Shock Resistance 800℃( Room Temperature) Cycle: 10 times   Pass Pass Pass - - -
Coefficient of Linear Expansion 20℃～100℃ ×10-6 K-1 - - -   ≤8 -
20℃～500℃ ×10-6 K-1 6.5～7.5 6.5～7.5 6.5～7.5 6.5～11.2 - -
20℃～800℃ ×10-6 K-1 6.5～8.0 6.5～8.0 6.3～7.3   - 4
20℃～1200℃ ×10-6 K-1 - 7.0～8.5 - - - -
Coefficient of Thermal Conductivity 20℃ W/(m·k) - - - - - 90～110
1000℃
Dielectric Constant 1MHz 20℃ - 9.0～10.5 9.0～10 9.0～10 - ≤7.5 -
1MHz 50℃ - - 9.0～10 - - - -
10GHz 20℃ - 9.0～10.5 9.0～10 9.0～10 - - -
Volume Resistivity 100℃ Ω·cm ≥1.0×1013 ≥1.0×1013 ≥1.0×1013 - ≥1.0×1012 -
300℃ ≥1.0×1013 ≥1.0×1010 ≥1.0×1013 - - -
500℃ ≥1.0×109 ≥1.0×108 -- - - -
Disruptive Strength D.C kV/mm ≥17 ≥15 ≥15 - ≥20 -
Chemical Durability 1:9HCl mg/c㎡ ≤0.7 ≤7.0 - - - -
10%NaOH mg/c㎡ ≤0.1 ≤0.2 - -- - -
Grain Size - μm - 3~12 - - - -



5. Process Flows:

Formulating --- Granulating --- Forming --- Sintering --- Grinding --- Printing --- Nickel Plating --- Assembing --- Brazing --- Inspecting --- Packing

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 0



6. Application Fields:

Widely apply for new energy vehicles, charging piles, solar power generation, energy storage and power storage system, electric vehicle power system and so on.

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 1



7. Production Facilities: Prilling Tower , Forming Machine , High Temperature Sintering Kiln

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 2



8. Detection Devices:

Electric Performance Tester , Film Thickness Analyzer , Granulometer , Helium Mass Spectrometer Leak Detector , Universal Pull Force Meter

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 3

9.Order Flow Steps as belows: Inquiry ---Quotation --- Place an order --- Production --- Delivery

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 4

10. Our advantages: Quality Assurance ; Price Competitive ; Factory Supply Directly ; Good Service

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 5

11.Shipping and Package:

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 6

12. Our aimed market :

High Purity 95% Electronic Ceramic Components 3.7-3.92 g/cc 7

 Notes:Above information only for reference and please contact with us for more details freely when you have any inquiry!
